5CBM Left hand drive airport fire truck

  • Category:Fire Truck
  • Views:1453
  • 5m3 tank capacity
  • Left hand drive only chassis
  • Euro 4 or Euro 5 emission
  • Product Manual:1.Common, middle and high level fire fighting truck products for different countries and regions; 2.Dongfeng, ISUZU, HOWO,JAC,JMC,FOTON chassis for option to meet different requests; 3.Different c
BASIC INFO Inquiry
5CBM Left hand drive airport fire truck
General Vehicle Brand XDR
Chassis Brand ISUZU
Overall Dimension 7065x2280x3140mm
GVW/Curb Weight 9775/6300kg
Front/rear track 1680/1650mm
Approach/departure angle 21/13 (°)
Front/rear suspension 1110/2050
Leaf spring 8/10+6
Cab Cab Seat 5,6
Air Conditioner optional
Chassis Drive Type 4x2
Transmission Manual
Wheelbase 4475
Tyre Specification 235/75R17.5
Tyre No. 6+1
Max Speed 90km/h
Brake Air brake
Engine Fuel Type diesel
Engie Model 4HK1-TC51
Engine Brand Dongfeng
Power 139kw/190hp
Displacement 5193cc
Emmission Standard Euro 5
Superstructure front and rear cupboard room, top mounted fire monitor,rear folding ladder, top mounted alarm and siren
Others water flow 30L/S
Pump PS30
Pressure 1.0Mpa
Fire distance 50m
Optional Colour for optional, LHD and RHD for optional,Air conditioner for optional
