Hubei Xindongri Special Vehicle Co., Ltd.

5-6 persons fire team vacancy fire truck

  • Category:Fire Truck
  • Views:1414
  • 4 doors cabin
  • 30L/S water flow
  • 50m fire distance
  • Product Manual:1.Common, middle and high level fire fighting truck products for different countries and regions; 2.Dongfeng, ISUZU, HOWO,JAC,JMC,FOTON chassis for option to meet different requests; 3.Different c
5-6 persons fire team vacancy fire truck
General Vehicle Brand XDR
Chassis Brand Dongfeng
Overall Dimension 6840x2190x3010mm
GVW/Curb Weight 8395kg
Front/rear track 1745/1620mm
Approach/departure angle 21/13 (°)
Front/rear suspension 1130/1910
Leaf spring 8/10+7
Cab Cab Seat 5,6
Air Conditioner optional
Chassis Drive Type 4x2
Transmission Manual
Wheelbase 3800
Tyre Specification 7.50R16
Tyre No. 6+1
Max Speed 95km/h
Paint Red or as request
Engine Fuel Type diesel
Engie Model CY4102BZQ
Engine Brand Dongfeng
Power 88kw/120hp
Displacement 3856cc
Emmission Standard Euro 3
Superstructure front and rear cupboard room, top mounted fire monitor,rear folding ladder, top mounted alarm and siren
Others water flow 30L/S
Pump PS30
Pressure 1.0Mpa
Fire distance 50m
Optional Colour for optional, LHD and RHD for optional,Air conditioner for optional
